Description
Designed for maximum environmental and electrical reliability, this connector features a robust brass body with tri-alloy (White Bronze) plating. This specialized finish provides the conductivity of silver with the durability of stainless steel, resisting oxidation in harsh outdoor environments. The internal PTFE (Teflon) dielectric ensures excellent thermal stability, allowing the connector to manage hundreds of watts of continuous RF power.
The crimp design utilizes a high-strength ferrule to secure the cable’s outer conductor, providing a 360-degree shield connection that is more uniform than manual soldering. The center contact is typically soldered or crimped to the inner conductor, ensuring a gas-tight electrical path. This construction is critical for achieving low PIM (typically ≤ -155 dBc), protecting the receiver sensitivity of sensitive base station hardware.
Key Technical Advantages
-
Rapid Field Installation: The crimp-on design allows for significantly faster assembly compared to solder-only connectors, making it ideal for high-volume site builds.
-
Vibration Resistance: The mechanical compression of the crimp ferrule provides superior pull-strength and electrical stability in high-vibration tower environments.
-
Low PIM Engineering: Constructed with non-magnetic materials and precision interfaces to maintain ultra-low PIM (≤ -155 dBc), essential for high-speed data integrity.
-
Weatherproof Design: When used with appropriate heat-shrink or weatherproofing boots, these connectors meet IP68 standards, shielding the cable core from moisture and corrosion.
-
Broadband Performance: Fully optimized for frequencies from DC to 6 GHz, covering all major sub-6GHz 5G, LTE, and CBRS bands.
Key Features
-
Cable Compatibility: LMR-400, RG-8, RG-213, Belden 9913, CFD400.
-
Impedance: 50 Ohm.
-
Frequency Range: DC to 6 GHz.
-
Connector Type: 7/16 DIN Male (Plug).
-
Body Plating: Tri-Alloy (White Bronze).
-
Attachment Method: Crimp (Outer) / Solder or Crimp (Inner).
🔹 Applications:
- RF cable termination for LMR400
- Telecom and antenna systems
- RF signal transmission networks
- Outdoor installations
- DAS systems
- Wireless communication infrastructure
