Description
The KMX3 series is a high-performance, subminiature RF interface specifically developed for the high-density requirements of modern digital telephony. This male (plug) variant is optimized for micro-diameter cables, including the low-loss LMR100, flexible RG174, and high-temperature RG316. The KMX3 interface is widely utilized in telecommunications for its space-saving snap-on coupling mechanism, which allows for rapid, tool-free mating and unmating while maintaining excellent electrical stability in high-density rack environments.
Maintaining a strict 75-Ohm impedance, this connector is essential for ensuring signal transparency in high-speed digital circuits, such as E1, E3, and DS3 telephony standards. It utilizes a professional dual-crimp termination system for both the center conductor and the outer ferrule, providing a gas-tight mechanical bond that resists vibration and cable strain. Manufactured with a gold-plated brass body and premium PTFE (Teflon) insulation, it delivers superior shielding effectiveness and low return loss, protecting sensitive digital data streams from electromagnetic interference (EMI).
Key Technical Advantages
-
Ultra-High Density Footprint: The subminiature snap-on design allows for maximum port density on equipment panels, making it ideal for compact telephony and video routing hardware.
-
Micro-Cable Precision Fit: Specifically calibrated for the dimensions of LMR100, RG174, and RG316 (approx. 2.5mm–2.8mm OD), ensuring an optimized electrical transition and consistent signal path.
-
75-Ohm System Integrity: Strictly calibrated to eliminate impedance mismatches, preventing bit errors and signal reflections in high-capacity digital circuits.
-
Rapid Dual-Crimp Assembly: The industrial-grade crimp design for both the center contact and outer sleeve provides a high-strength, repeatable termination for large-scale deployments.
-
Superior Corrosion Protection: Premium gold-over-nickel plating on all critical contact surfaces ensures low contact resistance and long-term durability in professional networking environments.
Key Features
-
Interface Type: KMX3 Male (Plug) with 75-Ohm impedance.
-
Coupling Mechanism: Snap-on / Push-pull for rapid deployment and high-density patching.
-
Termination Method: Dual-crimp (center pin and outer ferrule) for high-reliability mechanical bonding.
-
Cable Compatibility: Optimized for LMR100, RG174, and RG316 75-Ohm coaxial cables.
-
Premium Construction: Features a gold-plated brass body and a high-performance PTFE dielectric for electrical stability.
Technical Summary
| Parameter | Specification |
| Impedance | 75 Ohm |
| Frequency Range | DC – 2 GHz (Optimized for Telephony) |
| Body Material | Brass (Gold Plated) |
| Contact Material | Brass (Gold Plated) |
| Coupling Type | Snap-on |
| Insulator | PTFE (Teflon) |
| Operating Temp | -40°C ~ +85°C |
