BNC F BH CRIMP for BT3002 Cable

Description

The BNC female bulkhead crimp connector for BT3002 is a specialized RF component designed for seamless signal transition through enclosure walls and patch panels. This variant is optimized for the 3.55mm cable class, specifically calibrated for the unique dimensions of BT3002 (TZC75024) coaxial cable. Given that BT3002 is widely used for high-bit-rate digital signals in telecom exchanges, this connector ensures the precise 75-Ohm impedance matching required to minimize return loss and jitter in sensitive data circuits.

As a female interface (jack), it features the standard bayonet housing for rapid, vibration-resistant mating with BNC male plugs. The bulkhead mounting design includes a rear-fixing nut and washer, allowing the connector to be securely anchored to a panel or chassis. This connector utilizes a hex-crimp termination system for the outer conductor, providing a high-strength 360-degree mechanical bond and superior strain relief. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent electrical performance and long-term reliability for critical network infrastructure.

Key Technical Advantages

• Secure Bulkhead Mounting: The threaded body and rear-mount nut allow for a permanent, anti-rotation fixture on chassis walls and high-density DSX panels.

• Precision BT3002 Match: Specifically calibrated for the 3.55mm OD cable family, ensuring a precise mechanical fit and optimized electrical transition for telecommunications-grade coaxial lines.

• Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly, making it ideal for high-volume exchange wiring and signal distribution racks.

• 75-Ohm Impedance Optimized: Designed to maintain signal integrity for DS3 (45 Mbps) and E3 (34 Mbps) rates, effectively reducing bit error rates in digital transmission paths.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term protection in indoor telecom environments.

Key Features

• Interface Type: BNC Female (Jack) with standard bayonet coupling.

• Mounting Style: Bulkhead Front-Mount / Rear-Fixing Nut.

• Termination Method: Crimp (Outer Braid) / Solder or Crimp (Center Socket).

• Cable Compatibility: Optimized for BT3002, TZC75024, and equivalent 75-Ohm high-density telecommunications cables.

• Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.

• Common Application: DS3/E3 digital cross-connects, telecommunications switching enclosures, cellular backhaul racks, and internal chassis-to-external port transitions.

🔹 Applications:

• Bulkhead panel mounting
• RF interface connections
• Communication enclosures
• Antenna systems
• RF signal routing
• Industrial RF setups
