BNC F CRIMP for BT3002 Cable

Description

The BNC female crimp connector for BT3002 is a specialized RF component designed to meet the rigorous standards of telecommunications switching and transmission systems. This variant is optimized for the 3.55mm cable class, specifically calibrated for the unique dimensions of BT3002 (TZC75024) coaxial cable. Given that BT3002 is widely used for high-bit-rate digital signals in telecom exchanges, this connector ensures the precise 75-Ohm impedance matching required to minimize return loss and jitter in sensitive data circuits.

As a female interface (jack), it features the standard bayonet housing for rapid, vibration-resistant mating with BNC male plugs. This connector utilizes a hex-crimp termination system for the outer conductor, providing a high-strength 360-degree mechanical bond and superior strain relief for high-density cabling environments. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent electrical performance and long-term reliability for critical network infrastructure.

Key Technical Advantages

• Precision BT3002 Match: Specifically calibrated for the 3.55mm OD cable family, ensuring a precise mechanical fit and optimized electrical transition for telecommunications-grade coaxial lines.

• Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly, making it ideal for high-volume exchange wiring and digital signal cross-connect (DSX) panels.

• 75-Ohm Impedance Optimized: Designed to maintain signal integrity for DS3 (45 Mbps) and E3 (34 Mbps) rates, effectively reducing bit error rates in digital transmission paths.

• Standard Bayonet Housing: Features the industry-standard BNC female interface for rapid, tool-less mating that remains mechanically stable under vibration and constant movement.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term protection in indoor telecom environments.

Key Features

• Interface Type: BNC Female (Jack) with standard bayonet coupling.

• Termination Method: Crimp (Outer Braid) / Solder or Crimp (Center Socket).

• Cable Compatibility: Optimized for BT3002, TZC75024, and equivalent 75-Ohm high-density telecommunications cables.

• Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.

• Common Application: DS3/E3 digital cross-connects, central office switching equipment, cellular backhaul, and telecommunications transmission racks.
