BNC M CPS TYPE for BT3002 Cable

Description

The BNC male compression connector for BT3002 is a high-performance RF component designed to provide a superior electrical and mechanical bond for telecommunications-grade coaxial lines. This variant is specialized for the 3.55mm cable class, specifically optimized for the unique dimensions of BT3002 (TZC75024). The compression termination system utilizes a radial 360-degree interface to secure the cable, creating a high-pressure seal that ensures uniform grounding and eliminates signal leakage common in traditional crimping methods.

As a male interface (plug), it features the classic two-stud bayonet locking system for rapid, vibration-resistant mating with BNC jacks. The internal geometry is precision-matched to the 75-Ohm impedance of BT3002 cable, which is critical for maintaining signal integrity in high-bit-rate digital transmission paths within central offices and cellular backhaul hubs. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers superior return loss performance and long-term reliability for critical network infrastructure.

Key Technical Advantages

• 360-Degree Radial Compression: Provides a uniform, high-pressure mechanical bond that ensures maximum shielding effectiveness and high pull-off strength for high-density cabling.

• Precision BT3002 Match: Specifically calibrated for the 3.55mm OD cable family, ensuring a precise mechanical fit and optimized electrical transition for telecom-grade lines.

• 75-Ohm Impedance Optimized: Designed to minimize signal reflections and jitter for DS3 (45 Mbps) and E3 (34 Mbps) rates in digital cross-connect environments.

• Standard Bayonet Coupling: Features the industry-standard bayonet locking mechanism for tool-less mating that remains mechanically stable under vibration and constant movement.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center contact to ensure low contact resistance and long-term protection in indoor telecom environments.

Key Features

• Interface Type: BNC Male (Plug) with standard bayonet coupling.

• Termination Method: Compression (360-degree Radial).

• Cable Compatibility: Optimized for BT3002, TZC75024, and equivalent 75-Ohm high-density telecommunications cables.

• Premium Construction: Features a precision-machined brass body with a ruggedized internal compression sleeve.

• Common Application: DS3/E3 digital cross-connects, central office switching equipment, cellular backhaul, and high-reliability telecom transmission racks.

Technical Summary
