Description
The 7 dBi Panel Antenna is a wideband, directional RF component engineered to provide focused signal coverage. Its flat, compact design makes it an ideal choice for wall-mounted indoor applications or discreet outdoor installations. Because it covers the 698–2700 MHz spectrum, it is compatible with all major cellular bands used by global carriers, as well as the 2.4 GHz Wi-Fi band. This “all-in-one” capability allows it to enhance both voice and high-speed data transmission for mobile phones and wireless routers simultaneously.
Constructed with a UV-stabilized ABS radome, the antenna is built to withstand varied environmental conditions while maintaining a low profile. The directional radiation pattern—typically featuring a horizontal beamwidth of 65° to 70°—allows installers to direct the signal energy specifically where it is needed most, reducing interference and maximizing gain in the targeted area. Most professional models utilize an N-Female connector, ensuring a high-quality, low-loss connection to signal boosters, repeaters, or indoor IBS (In-Building Solution) networks.
Key Technical Advantages
-
Universal Wideband Support: Operates seamlessly across low-frequency 700 MHz bands and high-frequency 2700 MHz bands, supporting 2G, 3G, 4G LTE, and Wi-Fi.
-
Focused Directional Gain: The 7 dBi gain provides a significant signal boost over standard omnidirectional antennas, making it effective for targeting specific rooms or coverage sectors.
-
Compact Patch Design: The slim, rectangular form factor allows for unobtrusive mounting on walls or ceilings, blending easily into modern office or home decor.
-
Reliable Signal Integrity: Precision-engineered to maintain a VSWR of ≤1.5 to 1.7, ensuring maximum power efficiency and minimizing signal reflections.
-
Weatherproof Construction: Rated for a wide operating temperature range (typically -40°C to +65°C), making it suitable for both climate-controlled indoor spaces and outdoor environments.
Key Features
-
Antenna Type: Patch / Panel (Directional).
-
Frequency Range: 698–960 MHz / 1710–2700 MHz.
-
Gain: 7 dBi.
-
Polarization: Vertical.
-
Connector Type: N-Female (Standard).
-
Material: UV-Stabilized ABS Plastic.
-
Common Applications: Indoor cellular signal boosting, DAS (Distributed Antenna Systems), office Wi-Fi enhancement, and rural LTE gateways.
Technical Summary
| Parameter | Specification (Typical) |
| Frequency Range | 698 – 2700 MHz |
| Gain | 7 dBi |
| Horizontal Beamwidth | 65° – 70° |
| Vertical Beamwidth | 55° – 60° |
| VSWR | ≤ 1.5 |
| Impedance | 50 Ohm |
| Max Power Handling | 50 W |
| Mounting | Wall or Pole Mount |
