D4 M BT 3002 CRIMP

Description

The D4 Male to BT3002 Crimp Connector is a specialized RF termination designed to meet the rigorous standards of professional telecommunications infrastructure. It features the D4 (Male) interface, a push-pull locking system common in European and UK telecom markets, which provides a secure mechanical connection with a tactile confirmation. This specific variant is optimized for BT3002 (and equivalent) 75 Ohm micro-coaxial cables, utilized extensively in switching hubs and cellular backhaul.

This connector is indispensable for technicians building or maintaining digital distribution frames where space is at a premium and signal integrity is paramount. The crimp-crimp design ensures a robust physical attachment that can withstand the mechanical stress of high-density cabling. Precision-machined to maintain a constant 75 Ohm impedance, it is constructed with a durable gold-plated brass center contact and a nickel-plated body with PTFE (Teflon) insulation, ensuring ultra-low return loss and superior signal performance for high-speed digital data streams.

Key Technical Advantages

• Optimized for BT3002: Precision-sized internal dimensions and crimp sleeves ensure a perfect fit for BT3002 cable, preventing signal leakage and mechanical failure.

• Positive Push-Pull Locking: The D4 interface provides a secure, locked connection that resists accidental disconnection in crowded rack environments.

• High-Density Performance: The slim, compact design allows for maximum port density on DDF panels and telecommunications equipment.

• Superior EMI/RFI Shielding: The full-metal body and high-quality crimp termination provide a continuous shield transition, minimizing crosstalk and external interference.

• Maximum Conductivity: High-purity gold plating on the center contact pin ensures ultra-low contact resistance and protection against oxidation over thousands of mating cycles.

Key Features

• D4 Male Interface: Features the standard D4 (BT43 style) push-pull male plug with a precision-machined center pin.

• Crimp/Crimp Termination: Designed for professional crimp installation on both the center conductor and the outer braid for maximum pull strength.

• True 75 Ohm Impedance: Engineered specifically for telecommunications and digital signal standards to minimize signal reflection (VSWR).

• Nickel-Plated Brass Body: Offers superior corrosion resistance and professional-grade durability for central office and data center environments.

• Premium PTFE Dielectric: Provides high thermal stability and maintains consistent electrical performance for high-frequency digital transmission.

🔹 Applications:

• RF cable assemblies
• Communication systems
• Signal transmission setups
• Antenna connections
• Industrial RF applications
• Wireless systems
