TNC Male to TNC Female Adapter

Description

The TNC Male to TNC Female Adapter is a “between-gender” series adapter that allows for seamless transitions in RF layouts. The Threaded Neill-Concelman (TNC) interface is a threaded version of the BNC connector, favored for its superior mechanical stability and performance at microwave frequencies. This specific adapter is often used as a “port saver,” attached to expensive test equipment or base station ports to take the wear and tear of frequent mating cycles, thereby preserving the integrity of the primary hardware.

Crafted from Nickel-plated Brass or Stainless Steel, the adapter ensures superior durability and long-term corrosion resistance in harsh environments. The internal architecture features a Gold-plated or Silver-plated center contact to ensure ultra-low contact resistance. This ensures that signal loss is kept to an absolute minimum, which is critical for maintaining stable data links in avionics, military communications, and cellular infrastructure.

Key Technical Advantages

• Universal RF Compatibility: Connects any TNC-Male cable or antenna to a TNC-Female port, making it a “must-have” utility component for ruggedized wireless setups.

• Low Insertion Loss: Precision-machined to ensure that signal attenuation is negligible (typically ≤0.15 dB), preserving the strength of the transmitted or received signal.

• Vibration-Resistant Coupling: The 7/16-28 threaded mechanism provides a secure “locked” connection that outperforms bayonet-style connectors in high-shock environments.

• Broad Frequency Range: Maintains stable electrical performance across a wide spectrum (DC to 11 GHz), covering major sub-6 GHz 5G bands and Wi-Fi applications.

• Precision Construction: Manufactured to tight tolerances to ensure repeatable performance across hundreds of connect/disconnect cycles.

Key Features

• Adapter Type: Straight / Gender Transition.

• Interface: 1x TNC Male (Plug) and 1x TNC Female (Jack).

• Impedance: 50 Ohm.

• Body Material: Nickel-Plated Brass.

• Contact Material: Gold or Silver-Plated Beryllium Copper.

• Common Applications: Port protection for RF analyzers, avionics cable extensions, antenna repositioning, and military radio setups.

🔹 Applications:

• RF connector conversion
• Antenna cable connections
• Telecom and RF infrastructure
• Wireless communication systems
• RF signal routing
• Test setups
