Description
The 14dBi LPDA Antenna represents the peak of directional wideband performance for consumer and commercial signal enhancement. With a higher gain than standard 9dBi or 12dBi models, this antenna utilizes a longer boom and precisely calculated dipole elements to provide exceptional reach. It is specifically optimized for Sub-6 GHz 5G frequencies, including the critical C-band spectrum, while maintaining full backward compatibility with all global 4G LTE and legacy 3G bands.
The physical construction is designed for permanent, high-exposure outdoor mounting. It features a heavy-duty ABS radome or a powder-coated aluminum alloy frame that can withstand extreme weather and wind speeds of up to 200 km/h. The high front-to-back ratio ensures that the antenna focuses exclusively on the target cell tower while rejecting unwanted noise and interference. Most professional models come equipped with an N-Female connector, ensuring a robust, low-loss junction for high-performance RF cable assemblies.
Key Technical Advantages
-
Future-Proof 5G Coverage: Extends range up to 3800+ MHz to support the latest 5G mid-band frequencies (N77/N78), ensuring compatibility with the fastest modern data networks.
-
Maximum 14dBi Signal Boost: Provides the highest gain in the LPDA family, essential for locations several miles from the nearest tower where signal penetration is minimal.
-
Tight Directional Beamwidth: Focuses RF energy into a narrow beam to pull in distant signals while ignoring off-axis interference and multi-path reflections.
-
Low VSWR Performance: Precision-engineered to maintain a Voltage Standing Wave Ratio of ≤1.5 to 1.8, ensuring maximum power transfer and protecting connected radio equipment.
-
Industrial-Grade Durability: Rated for extreme temperatures and harsh outdoor environments, featuring UV-stabilized materials and DC ground lightning protection.
Key Features
-
Antenna Type: Log-Periodic Dipole Array (LPDA).
-
Frequency Range: 698–960 MHz / 1710–3800 MHz (Extended to 4000/4200 MHz).
-
Gain: 14 dBi.
-
Polarization: Vertical or Horizontal.
-
Connector Type: N-Female (Standard).
-
Housing Material: UV-Stabilized ABS or Aluminum Alloy.
-
Common Applications: 5G/4G rural broadband, remote IoT infrastructure, and high-performance donor antennas for cellular repeaters.
Technical Summary
| Parameter | Specification (Typical) |
| Frequency Range | 698 – 3800/4200 MHz |
| Gain | 14 dBi |
| VSWR | ≤ 1.5 – 1.8 |
| Front-to-Back Ratio | ≥ 18 – 20 dB |
| Input Impedance | 50 Ohm |
| Max Power Handling | 50 W – 100 W |
| Operating Temp | -40°C to +85°C |
