Description
The BNC female 4-hole panel mount crimp connector is a heavy-duty RF component designed for maximum mechanical stability at the enclosure interface. This variant is specialized for the 2.5mm to 3mm cable class, specifically optimized for high-performance LMR100, flexible RG174, and high-temperature RG316. Unlike standard bulkhead mounts, the 4-hole square flange design provides four distinct anchor points, preventing connector rotation and ensuring the assembly remains torque-resistant during repeated mating cycles.
As a female interface (jack), it features the standard bayonet housing for rapid, vibration-resistant mating with BNC male plugs. The connector utilizes a hex-crimp termination system for the outer conductor, providing a high-strength 360-degree mechanical bond. This combination of a secure flange mount and a robust crimp sleeve makes it ideal for transitioning RF signals through thick panels or internal chassis walls where environmental or mechanical stress is a factor. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it maintains consistent 50-Ohm performance and signal integrity across a wide range of mission-critical applications.
Key Technical Advantages
-
4-Hole Flange Stability: The square flange with four mounting holes offers superior anti-rotation and high-vibration resistance compared to single-nut bulkhead designs.
-
Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly, making it ideal for high-volume production, cabling workshops, and chassis integration.
-
Thin-Gauge Cable Match: Specifically calibrated for the 0.100″ to 0.110″ OD cable family, ensuring a precise mechanical fit and optimized electrical transition for LMR100 and RG316 lines.
-
Standard Bayonet Housing: Features the industry-standard BNC female interface for rapid, tool-less mating that remains mechanically stable under physical stress.
-
Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term environmental protection.
Key Features
-
Interface Type: BNC Female (Jack) with standard bayonet coupling.
-
Mounting Style: 4-Hole Square Flange Panel Mount.
-
Termination Method: Crimp (Outer Braid) / Solder (Center Socket).
-
Cable Compatibility: Optimized for LMR100, RG174, RG188, RG316, and equivalent 50-Ohm thin coaxial cables.
-
Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.
-
Common Application: Military communication panels, aerospace avionics racks, industrial control enclosures, and high-vibration instrumentation.
🔹 Applications:
- Panel-mounted RF interfaces
- Compact RF systems
- Communication equipment enclosures
- PCB and module connections
- Test equipment
- IoT systems
