Description
Built for infrastructure-grade reliability, this connector features a precision-machined brass body typically finished with tri-alloy (white bronze) plating to ensure superior conductivity and long-term corrosion resistance. The 4-hole flange design prevents the connector from rotating or loosening under the high installation torque (up to 30 Nm) required for 7/16 DIN interfaces.
Internally, high-grade PTFE (Teflon) insulation provides excellent thermal stability and high voltage insulation, allowing the connector to manage hundreds of watts of continuous RF power. The silver-plated center contact ensures a low-resistance signal path, which is critical for maintaining clean signal transmission in sensitive 4G and 5G network environments.
Key Technical Advantages
-
Mechanical Stability: The 4-hole square flange ensures a permanent, rotation-proof mount and provides a solid mechanical ground to the chassis.
-
Low PIM Engineering: Constructed with non-magnetic materials to minimize Passive Intermodulation, protecting the sensitivity of modern multi-carrier receivers.
-
Superior Power Handling: Designed to dissipate significant RF energy, making it ideal for the primary output stages of high-power transmitters.
-
Broadband Precision: Fully optimized for frequencies from DC to 7.5 GHz, covering all major sub-6GHz 5G and satellite bands.
-
Durable Construction: The robust 7/16 DIN standard is designed for longevity, maintaining its electrical specifications over hundreds of mating cycles.
Key Features
-
Mounting Type: 4-Hole Square Flange / Panel Mount.
-
Terminal Type: Solder Cup or Solder Tab.
-
Impedance: 50 Ohm.
-
Frequency Range: DC to 7.5 GHz.
-
Body Plating: Tri-Alloy (White Bronze) or Silver.
-
Dielectric: PTFE (Teflon).
🔹 Applications:
- RF panel mounting in telecom equipment
- Cabinet and rack RF signal routing
- Test and measurement panels
- Antenna interface modules
- Industrial RF enclosures
- Communication hardware integration
