SMA M RA CRIMP for RG58/RG142/LMR195/LMR200 Cable

Description

The SMA Male Right-Angle Crimp Connector is a precision RF component designed for applications where space is limited and cable routing requires a sharp turn. Unlike straight connectors, the 90-degree geometry allows the cable to exit parallel to the connection interface, which significantly reduces the depth required for installation and prevents mechanical stress on the cable’s internal layers.

This connector is compatible with a wide range of mid-sized flexible cables, including high-performance low-loss versions like LMR195 and LMR200. The termination process utilizes a hex-crimp method for the outer ferrule, creating a permanent, 360-degree mechanical bond that ensures maximum pull-strength and superior electrical grounding. Constructed with a gold-plated brass body and high-purity PTFE (Teflon) insulation, it maintains exceptional signal integrity and low VSWR across frequencies up to 12.4 GHz.

Key Technical Advantages

• Space-Efficient 90? Routing: Ideal for mounting in dense RF racks, small enclosures, or behind equipment where straight connectors would be too long.

• Broad Cable Support: A versatile design that fits multiple popular cables including RG58, RG142, and LMR200, simplifying inventory for custom pigtail assemblies.

• High-Strength Crimp Bond: The hex-crimp ferrule provides a rugged, vibration-proof attachment that is more reliable than twist-on or solder-only outer terminations.

• Superior RF Shielding: The 360-degree ferrule crimp ensures a continuous ground path, providing excellent EMI/RFI protection and minimal signal leakage.

• Maximum Conductivity: High-purity gold plating on the center pin and body minimizes contact resistance and prevents environmental oxidation.

Key Features

• 90-Degree Configuration: Minimizes the required bend radius of the cable, extending the life of the assembly.

• Standard SMA Male Interface: Features internal threads and a protruding gold-plated center pin.

• Premium PTFE Dielectric: High-grade insulator ensures thermal stability during assembly and low signal loss at microwave frequencies.

• Rugged 3-Piece Construction: Includes the right-angle body, center contact pin, and outer crimp ferrule for straightforward installation.

• High Durability: Rated for at least 500 mating cycles while maintaining stable electrical performance.

🔹 Applications:

• Right Angle Cable Termination for RG58 / RG142 / LMR195 / LMR200
• RF Signal Routing in Compact & Space-Constrained Installations
• RF Coaxial Cable Assemblies
• WiFi Antenna & Router Connections
• Wireless Communication Systems
• IoT & Embedded RF Modules
• Telecom Equipment Installations
• RF Test & Measurement Equipment
• WLAN Network Devices
