BNC M RP CRIMP for BT3002 Cable

Description

The RP-BNC male crimp connector for BT3002 is a specialized RF component that combines the standard BNC bayonet housing with a Reverse Polarity internal structure. In this configuration, the male plug housing contains a female center socket instead of the standard male pin. This variant is optimized for the 3.55mm cable class, specifically calibrated for the unique dimensions of BT3002 (TZC75024) coaxial cable, ensuring precise 75-Ohm impedance matching required for high-bit-rate digital transmission.

As an RP-BNC male interface, it features the classic two-stud bayonet locking system for rapid, vibration-resistant mating. This connector utilizes a hex-crimp termination system for the outer conductor, providing a high-strength 360-degree mechanical bond and superior strain relief. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent electrical performance and long-term reliability for critical network infrastructure and specialized RF applications.

Key Technical Advantages

• Reverse Polarity Configuration: Prevents accidental mating with standard BNC interfaces, meeting specific regulatory or equipment security requirements for unique signal paths.

• Precision BT3002 Match: Specifically calibrated for the 3.55mm OD cable family, ensuring a precise mechanical fit and optimized electrical transition for telecommunications-grade coaxial lines.

• Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly, making it ideal for exchange wiring and specialized digital signal cross-connect (DSX) panels.

• 75-Ohm Impedance Optimized: Designed to maintain signal integrity for high-speed digital rates, effectively reducing bit error rates in specialized transmission paths.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term protection in indoor telecom environments.

Key Features

• Interface Type: RP-BNC Male (Plug) with Female Center Socket.

• Termination Method: Crimp (Outer Braid) / Solder or Crimp (Center Socket).

• Cable Compatibility: Optimized for BT3002, TZC75024, and equivalent 75-Ohm high-density telecommunications cables.

• Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.

• Common Application: Specialized telecommunications switching, proprietary RF equipment, and secure digital transmission racks.

Technical Summary
