DB 37 F WITH HOOD (METAL)

Description

The DB37 Female with Metal Hood is a heavy-duty connectivity solution designed for professional cable fabrication where high pin-count signal integrity and hardware durability are paramount. It consists of a Standard-Density DB37 Jack (Female), featuring two rows of high-retention sockets (19 pins and 18 pins), and a Die-Cast Metal Backshell (Hood). The connector utilizes solder-cup terminations, providing a high-integrity electrical bond for multi-conductor shielded cables or complex discrete wire looms.

This assembly is essential for high-reliability applications such as industrial PLC networking, aerospace control systems, and high-density analog signaling where external noise is a factor. The zinc die-cast metal hood provides full 360-degree shielding, effectively creating a Faraday cage to protect sensitive data lines from electromagnetic interference. The rugged housing and multi-stage strain relief system ensure the connection remains secure and intact, even in environments subject to extreme vibration or mechanical stress.

Key Technical Advantages

• Exceptional EMI/RFI Shielding: The die-cast metal housing provides maximum attenuation of external noise, ensuring clear signal transmission for high-speed serial and parallel data.

• Rugged Mechanical Protection: The zinc-alloy construction offers superior resistance to impact and crushing compared to plastic alternatives, making it ideal for harsh industrial floors.

• High-Density Signal Management: Efficiently manages 37 independent signal paths within a single, robust D-Sub interface.

• Enhanced Strain Relief: Features a heavy-duty internal cable clamp that secures the cable jacket, transferring all mechanical tension away from the soldered wire terminations.

• Maximum Conductivity: Gold-flashed or gold-plated female sockets ensure ultra-low contact resistance and long-term protection against oxidation in diverse environments.

Key Features

• DB37 Female Interface: Two-row, 37-pin D-Sub configuration with precision-formed internal sockets.

• Die-Cast Zinc Metal Hood: Finished with professional-grade plating for corrosion resistance and industrial durability.

• Solder Cup Terminals: Concave termination points designed for high-strength wire attachment and easy manual soldering.

• Complete Hardware Set: Includes long jackscrews, nuts, and internal metal clamps for a secure, locked connection to mating DB37 male interfaces.

• Professional Grade Reliability: Specifically engineered for permanent installations and field environments where mechanical failure is not an option.
