N M CLAMP for 1/2″ Feeder Cable

Description

The N-Type connector is the premier choice for infrastructure-grade RF applications, valued for its high power handling and environmental durability. This male (plug) variant is specialized for the 1/2″ corrugated cable class, specifically optimized for high-performance feeder lines. Unlike connectors for flexible braided cables, this variant utilizes a mechanical compression clamp termination designed to grip the solid, annularly corrugated copper outer conductor. This ensures an airtight, low-resistance electrical bond that maintains superior Passive Intermodulation (PIM) performance over long-term deployments.

The clamp design is essential for field-serviceability, allowing for precision, high-strength terminations without the need for specialized hydraulic crimping tools. It provides a permanent mechanical seal that prevents the heavy cable from twisting or pulling out under environmental stress. Manufactured with a reinforced tri-metal (Albaloy) or nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and low VSWR up to 18 GHz. The integrated O-ring gaskets provide an IP68-rated moisture barrier, ensuring total reliability in exposed outdoor environments and high-capacity wireless installations.

Key Technical Advantages

• 1/2″ Corrugated Cable Match: Specifically engineered for the annular corrugation profile of 1/2″ cables, ensuring maximum surface contact for superior electrical conductivity and extreme pull-off strength.

• Low-PIM Performance: The precision-machined clamp interface minimizes non-linearities, a critical requirement for modern 5G, LTE, and multi-carrier cellular infrastructure to prevent signal interference.

• Field-Installable Design: The mechanical compression system allows for high-integrity assembly using standard wrenches, facilitating efficient on-site feeder termination and tower repairs.

• Rugged Environmental Sealing: Features multiple integrated gaskets and O-rings to provide a complete weather-proof seal, protecting the cable dielectric from moisture ingress and oxidation.

• Vibration-Proof Threaded Interface: The 5/8-24 threaded coupling provides a secure mechanical lock with high torque capability, ensuring stable performance in high-wind and high-vibration outdoor environments.

Key Features

• Interface Type: N-Type Male (Plug) with standard 5/8-24 threaded coupling.

• Termination Method: Compression Clamp (Outer Conductor) / Solder or Captive (Center Pin).

• Cable Compatibility: Optimized for 1/4″ Annular Corrugated Feeder Cables (LDF4-50A, AVA5-50, SCF12-50, etc.).

• Premium Construction: Features a tri-metal plated brass body and high-performance PTFE dielectric.

• Common Application: Macro cell sites, cellular base station feeder lines, rooftop antenna arrays, and high-power radio transmitters.

🔹 Applications:

• Telecom feeder cable connections
• Base station systems
• Antenna installations
• RF signal transmission
• DAS systems
• Outdoor RF setups
