Description
Engineered for infrastructure-grade reliability, this connector features a robust brass body typically finished with tri-alloy (White Bronze) plating. This finish offers the electrical conductivity of silver with the durability of stainless steel, protecting against oxidation in harsh outdoor environments. The internal PTFE (Teflon) dielectric ensures excellent thermal stability and high voltage insulation.
The crimp design utilizes a precision-sized ferrule to secure the cable’s outer conductor, providing a 360-degree shield connection that is more uniform and vibration-resistant than manual soldering. The center contact is typically soldered or crimped to the cable’s inner conductor to ensure a gas-tight electrical path, which is critical for maintaining low Passive Intermodulation (PIM) and protecting receiver sensitivity.
Key Technical Advantages
-
Space-Efficient Connectivity: Allows for the use of flexible, small-diameter LMR-200 cable while maintaining compatibility with heavy-duty 7/16 DIN infrastructure.
-
Rapid Field Installation: The crimp termination method is significantly faster than traditional solder-only connectors, making it ideal for high-volume site builds.
-
Vibration Resistance: The mechanical compression of the crimp ferrule provides superior pull-strength and electrical stability in high-vibration environments like tower tops.
-
Low PIM Engineering: Constructed with non-magnetic materials to achieve ultra-low PIM (typically ≤ -155 dBc), essential for high-speed data integrity.
-
Weatherproof Reliability: When paired with appropriate heat-shrink or weatherproofing boots, these connectors meet IP67/IP68 standards, shielding the cable core from moisture.
Key Features
-
Cable Compatibility: LMR-200, CFD200, RG-58, Belden 9310.
-
Impedance: 50 Ohm.
-
Frequency Range: DC to 6 GHz.
-
Connector Type: 7/16 DIN Male (Plug).
-
Body Plating: Tri-Alloy (White Bronze).
-
Attachment Method: Crimp (Outer) / Solder or Crimp (Inner).
🔹 Applications:
- RF cable assemblies for compact systems
- Indoor telecom setups
- Antenna connections
- RF testing environments
- Wireless communication systems
- Signal routing
