2 W TNC M DUMMY LOAD 4GHZ

Description

The 2W TNC dummy load is specifically chosen for applications where the quick-release bayonet of a BNC might fail due to mechanical stress or movement. It utilizes a precision-ground 50 Ohm resistive element and PTFE (Teflon) dielectric to maintain electrical consistency across the DC to 4 GHz spectrum. The threaded interface ensures a constant, high-pressure contact that minimizes signal leakage and intermodulation.

This terminator is a critical tool for isolating ports on outdoor wireless equipment, telemetry systems, and ruggedized test benches. The 2-Watt rating provides a significant safety margin over standard 1W units, allowing for continuous operation in moderate-power environments without thermal drift. Its design is optimized for durability, supporting hundreds of mating cycles while resisting oxidation and environmental wear.

Key Technical Advantages

• Vibration-Proof Connection: The threaded TNC interface prevents accidental disconnection and maintains signal integrity in high-movement environments.

• Moderate Power Handling: Rated for 2 Watts continuous power, ensuring reliable performance during signal testing and system calibration.

• Low Reflection Coefficient: Maintains a consistent 50 Ohm match to keep reflected power low, shielding the output stages of transmitters and amplifiers.

• Superior Environmental Resistance: Often features weather-resistant gaskets and robust plating, suitable for both laboratory and harsh field deployments.

• Broadband Stability: Engineered to perform reliably up to 4 GHz, covering a wide array of public safety, industrial, and legacy cellular bands.

Key Features

• Impedance: 50 Ohm (±1 Ohm).

• Power Rating: 2 Watts (Continuous).

• Frequency Range: DC to 4 GHz.

• Connector Type: TNC Male (Plug).

• Coupling: Threaded (7/16-28).

• Applications: Aerospace Telemetry, Industrial Wireless, and Military Communications.

Technical Summary
