BNC F BH PCB MOUNT SOLDER

Description

The BNC female bulkhead PCB mount connector is a specialized RF component designed to provide a robust mechanical and electrical bridge between a printed circuit board (PCB) and an external chassis port. This variant features a straight body configuration, allowing the BNC interface to emerge through an enclosure wall while the connector pins are soldered directly into the PCB traces. This design is essential for maintaining a clean signal path in vertically integrated assemblies or stacked PCB configurations.

As a female interface (jack), it features the standard bayonet housing for rapid, vibration-resistant mating with BNC male plugs. The bulkhead mounting feature includes a threaded front-mount body with a lock washer and nut, ensuring that mechanical stress from mating cables is transferred to the chassis rather than the delicate solder joints on the PCB. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it maintains consistent impedance and high signal integrity, making it ideal for precision instrumentation and high-reliability communication modules.

Key Technical Advantages

• Chassis-to-Board Stability: Combines PCB through-hole mounting with a threaded bulkhead interface, providing maximum mechanical security and preventing board-level fatigue.

• Streamlined Straight Design: The vertical orientation is perfect for panels where the PCB is mounted parallel to the enclosure face, ensuring a direct and low-loss signal transition.

• Direct Solder Termination: Features precision-machined solder pins for the center conductor and multiple grounding legs, ensuring a permanent, low-resistance connection to the circuit traces.

• Standard Bayonet Housing: Features the industry-standard BNC female interface for rapid, tool-less mating that remains mechanically stable under physical stress.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term protection against environmental oxidation.

Key Features

• Interface Type: BNC Female (Jack) with standard bayonet coupling.

• Mounting Style: Bulkhead Front-Mount with Straight PCB Through-Hole pins.

• Termination Method: Solder (Through-Hole).

• Body Configuration: Straight (Vertical).

• Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.

• Common Application: RF test equipment, telecommunications base stations, industrial control modules, and video processing hardware.

Technical Summary
