BNC F CRIMP for LMR240 Cable

Description

The BNC female crimp connector is a foundational RF component valued for its rapid bayonet coupling and robust mechanical interface. This variant is specialized for the 6mm cable class, specifically optimized for high-performance, low-loss LMR240 and its flexible variants. As a female interface (jack), it is designed to receive the center pin and bayonet studs of a standard BNC male plug, providing a positive, vibration-resistant connection.

This connector utilizes a hex-crimp termination system for the outer conductor, providing a high-strength 360-degree mechanical bond and excellent strain relief for the specialized shielding of LMR-series cables. Often used in bulkhead or panel-mount configurations, this jack allows for the seamless transition of RF signals through enclosures while maintaining the low-loss characteristics of the LMR240 line. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable signal integrity across a wide range of wireless networking and industrial applications.

Key Technical Advantages

• Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly, making it ideal for high-volume production, cabling workshops, and field-installed wireless links.

• Precision LMR240 Match: Specifically calibrated for the 0.240″ OD cable family, ensuring a precise mechanical fit and optimized electrical transition for low-loss coaxial lines.

• Standard Bayonet Housing: Features the industry-standard BNC female interface for rapid, tool-less mating that remains mechanically stable under vibration and movement.

• High Mechanical Stability: The crimp sleeve provides superior pull-off resistance and robust strain relief, maintaining electrical contact even under physical stress.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term protection against oxidation.

Key Features

• Interface Type: BNC Female (Jack) with standard bayonet coupling.

• Termination Method: Crimp (Outer Braid) / Solder (Center Socket).

• Cable Compatibility: Optimized for LMR240, RG8X, and equivalent 50-Ohm 0.240″ diameter coaxial cables.

• Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.

• Common Application: Wireless base stations, antenna jumpers, RF signal distribution, and internal equipment jumpers.

🔹 Applications:

• Medium power RF cable assemblies
• Telecom systems
• Antenna connections
• RF signal routing
• Wireless communication
• Test setups
