BNC F CRIMP for RG58/RG142/LMR195/LMR200 Cable

Description

The BNC female crimp connector is a foundational RF component valued for its rapid bayonet coupling and robust mechanical interface. This variant is specialized for the 5mm cable class, specifically optimized for standard RG58, high-performance LMR195/LMR200, and high-temperature RG142. As a female interface (jack), it is designed to receive the center pin and bayonet studs of a standard BNC male plug, providing a positive, vibration-resistant connection.

This connector utilizes a hex-crimp termination system for the outer conductor, providing a high-strength 360-degree mechanical bond and excellent strain relief for flexible coaxial lines. Often used in bulkhead or panel-mount configurations, this jack allows for the seamless transition of RF signals through enclosures. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable signal integrity across a wide range of wireless networking, broadcast, and industrial applications.

Key Technical Advantages

• Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly, making it ideal for high-volume production, cabling workshops, and field-installed infrastructure.

• Medium-Gauge Cable Match: Specifically calibrated for the 0.195″ to 0.200″ OD cable family, ensuring a precise mechanical fit and optimized electrical transition for RG58 and LMR-series lines.

• Standard Bayonet Housing: Features the industry-standard BNC female interface for rapid, tool-less mating that remains mechanically stable under vibration and movement.

• High Mechanical Stability: The crimp sleeve provides superior pull-off resistance and robust strain relief, maintaining electrical contact even under physical stress.

• Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center socket to ensure low contact resistance and long-term protection against oxidation.

Key Features

• Interface Type: BNC Female (Jack) with standard bayonet coupling.

• Termination Method: Crimp (Outer Braid) / Solder (Center Socket).

• Cable Compatibility: Optimized for RG58, RG142, RG223, LMR195, LMR200, and equivalent 50-Ohm medium coaxial cables.

• Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.

• Common Application: Bulkhead panel mounts, wireless base stations, RF signal distribution, and internal equipment jumpers.

🔹 Applications:

• RF cable connections
• CCTV and broadcast systems
• Communication equipment
• Antenna systems
• RF signal routing
• Test setups
