Description
The BNC male crimp connector is a foundational RF component valued for its quick-connect/disconnect bayonet coupling and robust mechanical interface. This variant is specialized for the .141-inch cable class, specifically optimized for solid-jacket Semi-Rigid and hand-formable RG402 cables. While many .141 assemblies utilize solder-on connectors, this crimp-style model provides a faster termination process without sacrificing the mechanical integrity required for industrial and field applications.
As a male interface (plug), it features the industry-standard two-stud bayonet locking system designed for secure engagement with BNC jacks. This connector utilizes a precision crimp termination for the outer conductor, providing a high-strength 360-degree mechanical bond. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable operation across the microwave spectrum, ensuring signal integrity in sophisticated test equipment and wireless systems.
Key Technical Advantages
-
Efficient Crimp Termination: The hex-crimp design allows for rapid, repeatable assembly compared to traditional solder-only methods, making it ideal for high-volume production and field repairs.
-
Precision .141/RG402 Match: Specifically calibrated for the 0.141-inch OD jacket, ensuring a precise mechanical fit and optimized electrical transition for semi-rigid cable families.
-
Secure Bayonet Coupling: Features the classic bayonet locking mechanism for tool-less, rapid mating that remains secure under vibration and mechanical movement.
-
High Mechanical Stability: The crimp sleeve provides superior pull-off resistance and excellent strain relief, maintaining electrical contact even under physical stress.
-
Superior Corrosion Resistance: Features a precision-machined nickel-plated body and gold-plated center contact to ensure low contact resistance and long-term environmental protection.
Key Features
-
Interface Type: BNC Male (Plug) with standard bayonet coupling.
-
Termination Method: Crimp (Outer Jacket) / Solder or Crimp (Center Pin).
-
Cable Compatibility: Optimized for .141 Semi-Rigid, RG402, and hand-formable 0.141″ 50-Ohm coaxial cables.
-
Premium Construction: Features a precision-machined brass body and high-performance PTFE dielectric.
-
Common Application: RF test benches, microwave subsystems, telecommunications jumpers, and ruggedized signal distribution.
🔹 Applications:
- RF cable termination
- Semi-rigid RF assemblies
- Communication systems
- RF signal transmission
- Test setups
- Lab applications
