DIN 1.6/5.6 or L9 M RA CRIMP for BT3002 Cable

Description

The DIN 1.6/5.6 series, universally recognized as the L9 connector, is a high-performance RF interface designed specifically for the rigorous demands of digital telephony. This male (plug) variant features a 90-degree right-angle configuration, which is critical for optimizing cable management in shallow equipment racks and high-density Digital Distribution Frames (DDF). The right-angle orientation allows the BT3002 cable to exit parallel to the equipment faceplate, significantly reducing mechanical stress on the interface and protecting the cable’s minimum bend radius in tight spaces.

Specifically calibrated for BT3002 (Type 2002)—the industry-standard 75-Ohm cable for E1, E3, and DS3 digital transmission—this connector maintains strict impedance control. It utilizes a professional dual-crimp termination for both the center pin and the outer ferrule, ensuring a gas-tight mechanical bond and superior pull-off resistance. Manufactured with a gold-plated brass body and premium PTFE (Teflon) insulation, it delivers exceptional signal integrity and high shielding effectiveness, protecting sensitive digital data streams from electromagnetic interference in congested exchange environments.

Key Technical Advantages

• Space-Saving 90° Integration: The right-angle body minimizes protrusion from the front panel, making it ideal for high-density patching where rack depth is limited.

• BT3002 Precision Matching: Engineered specifically for the geometry of Type 2002 cable, ensuring an optimized electrical transition and minimal return loss for UK and European telecommunications standards.

• 75-Ohm System Integrity: Specifically calibrated to eliminate impedance mismatches, preventing bit errors and signal jitter in high-capacity digital circuits.

• Rapid Dual-Crimp Assembly: The industrial crimp design provides a high-strength, repeatable termination that is more consistent than soldering for large-scale telephony deployments.

• Superior Corrosion Protection: Premium gold-over-nickel plating on all critical contact surfaces ensures low contact resistance and long-term durability in mission-critical infrastructure.

Key Features

• Interface Type: DIN 1.6/5.6 (L9) Male (Plug) with 75-Ohm impedance.

• Orientation: 90° Right Angle for low-profile cable management.

• Termination Method: Dual-crimp (center pin and outer ferrule) for high-reliability mechanical bonding.

• Cable Compatibility: Optimized exclusively for BT3002 (Type 2002) 75-Ohm coaxial cable.

• Premium Construction: Features a gold-plated brass body and a high-performance PTFE dielectric for electrical stability.

Technical Summary
