Description
The F-series is the global benchmark for broadband, satellite, and digital video distribution. This female (jack) variant is specifically optimized for RG6 coaxial cable, the primary standard for modern residential and commercial signal routing. Designed to accommodate the dielectric and shielding dimensions of RG6, this connector ensures a secure mechanical fit and a seamless electrical transition, maintaining a strict 75-Ohm impedance to prevent signal reflections and data loss.
This connector utilizes a professional crimp termination system. By using a standard hex-crimp tool on the outer ferrule, it creates a 360-degree mechanical bond with the cable’s outer jacket and braid. This provides exceptional pull-off resistance and high shielding effectiveness against electromagnetic interference (EMI) and radio frequency interference (RFI). Manufactured with a nickel-plated brass body and premium dielectric insulation, it is designed for long-term durability in both indoor headend environments and outdoor utility enclosures.
Key Technical Advantages
-
RG6 Precision Calibration: Specifically engineered to fit standard RG6 cable dimensions, ensuring an optimized electrical path and preventing mechanical stress on the cable core.
-
Low-Loss 75-Ohm System Match: Engineered to maintain impedance stability up to 3 GHz, making it fully compatible with 4K Ultra-HD signals and high-speed DOCSIS data.
-
High-Reliability Crimp Design: Provides a permanent, vibration-proof termination that meets industrial pull-out standards, essential for reliable backbone infrastructure.
-
Superior EMI/RFI Protection: The robust metal construction and secure crimp seal protect sensitive digital streams from external signal ingress.
-
Streamlined Bulkhead Mounting: The slim female profile is ideal for custom wall plates, bulkhead mounts, and specialized digital distribution panels where space is a priority.
Key Features
-
Interface Type: F-Type Female (Jack) with 75-Ohm impedance.
-
Termination Method: Crimp (utilizing an outer ferrule) for high-strength mechanical bonding.
-
Cable Compatibility: Optimized for standard RG6 and RG6-Tri shield coaxial cables.
-
Premium Construction: Features a nickel-plated brass body for high conductivity and environmental resistance.
-
Industrial Application: Ideal for digital distribution frames (DDF), satellite patching, and professional video surveillance systems.
Technical Summary
| Parameter | Specification |
| Impedance | 75 Ohm |
| Frequency Range | DC – 3 GHz |
| Body Material | Brass (Nickel Plated) |
| Contact Material | Beryllium Copper or Brass (Gold/Tin Plated) |
| Coupling Mechanism | Threaded (3/8-32 UNEF) |
| Termination Style | Hex Crimp |
| Operating Temp | -40°C ~ +85°C |
