Description
The MMCX (Micro-Miniature Coaxial) male connector is a high-performance RF component valued for its exceptionally small footprint and ability to maintain signal integrity at microwave frequencies. This variant is specialized for the .086-inch cable class, specifically optimized for solid-jacket Semi-Rigid and hand-formable RG405 cables. The snap-on coupling mechanism allows for 360-degree rotation after mating, which is essential for relieving mechanical stress in rigid cable assemblies.
This connector utilizes a direct-solder termination for both the center conductor and the outer jacket. By soldering the cable’s copper jacket directly into the precision-machined rear bore of the gold-plated connector body, the assembly achieves an airtight, 360-degree electrical bond. This method is superior for maintaining maximum shielding effectiveness and ensuring the lowest possible VSWR in high-frequency applications. Manufactured with a gold-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable operation up to 6 GHz.
Key Technical Advantages
-
Direct-Solder Integrity: The solder-on body interface creates a continuous metallic shield with the cable jacket, providing maximum EMI/RFI protection essential for sensitive microwave systems.
-
Precision .086/RG405 Match: Specifically calibrated for the 0.086-inch OD jacket, ensuring an optimized electrical transition and high mechanical rigidity for small-form-factor applications.
-
Micro-Miniature Snap-On Design: The ultra-compact interface enables high-density packaging on PCBs and within modular RF housings where space is extremely limited.
-
Phase-Stable Performance: The permanent solder bond minimizes signal fluctuations and non-linearities, making it ideal for precision micro-jumpers and internal equipment routing.
-
Superior Conductivity: Features heavy gold plating on the body and center contact to ensure low contact resistance and long-term protection against oxidation.
Key Features
-
Interface Type: MMCX Male (Plug) with snap-on coupling mechanism.
-
Termination Method: Solder (Outer Jacket) / Solder (Center Pin).
-
Cable Compatibility: Optimized for .086 Semi-Rigid, RG405, and hand-formable 0.086″ 50-Ohm coaxial cables.
-
Premium Construction: Features a precision-machined gold-plated brass body and high-performance PTFE dielectric.
-
Common Application: Microwave modules, high-frequency PCB-to-chassis links, RF power dividers, and phase-stable instrumentation.
🔹 Applications:
- High-frequency RF cable assemblies
- Microwave communication systems
- Test and measurement setups
- Precision RF circuits
- Lab calibration
- Aerospace RF systems
