N F RA CLAMP for LMR240 Cable

Description

The N-Type female connector is a cornerstone of high-reliability RF systems, valued for its mechanical durability and superior power handling. This Right Angle (RA) variant is specialized for the 6.1mm (0.240″) cable class, specifically optimized for high-performance LMR240. The 90-degree elbow configuration is essential for installations with limited vertical or horizontal clearance, allowing for streamlined cable routing in cramped enclosures without exceeding the cable’s minimum bend radius.

Unlike crimp-style connectors, this variant utilizes a mechanical clamp termination system. This design employs an internal compression sleeve and a rear fastening nut to secure the cable braid, providing a high-strength, reusable connection that can be assembled on-site with standard wrenches. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable operation up to 11 GHz. The integrated gaskets ensure a stable moisture barrier, making it suitable for both indoor and outdoor communication systems where space and signal integrity are equally critical.

Key Technical Advantages

• Space-Saving 90° Routing: Significantly reduces the depth required for connections, facilitating high-density cable management in small enclosures and equipment racks.

• LMR240 Precision Match: Specifically calibrated for the 0.240-inch OD cable family, ensuring maximum pull-off resistance and an optimized electrical transition for mid-sized, low-loss coaxial lines.

• Field-Installable Design: The clamp-style assembly allows for high-integrity terminations without the need for specialized crimping tools, ideal for on-site repairs and custom installations.

• Vibration-Proof Threaded Interface: The 5/8-24 threaded outer shell ensures a secure, locked mating with male connectors that resists loosening in high-vibration or outdoor environments.

• High-Grade Materials: Features a nickel-plated brass body and a gold-plated center contact for maximum corrosion resistance and consistent signal clarity over the life of the product.

Key Features

• Interface Type: N-Type Female (Jack) Right Angle (90°) with standard 5/8-24 threaded outer shell.

• Termination Method: Clamp (Outer Braid) / Solder (Center Pin).

• Cable Compatibility: Optimized for LMR240 and equivalent 0.240″ 50-Ohm coaxial cables.

• Premium Construction: Features a nickel-plated brass body and high-performance PTFE dielectric.

• Common Application: Cellular base station panels, WLAN antenna arrays, cabinet cable routing, and industrial RF enclosures.

🔹 Applications:

• Right-angle RF cable routing
• Antenna systems
• Communication setups
• Signal routing
• Wireless communication
• RF installations
