N Female to BNC Female Adapter

Description

The N Female to BNC Female Adapter is a specialized “between-series” RF component designed to provide a high-reliability transition between two widely used connector standards. It features an N-Type Jack (Female) on one side, utilizing the standard threaded interface common in wireless infrastructure, and a BNC Jack (Female) on the other, featuring the classic two-stud bayonet coupling mechanism used for rapid laboratory and video connections.

This adapter is essential for engineers and technicians who need to join N-Type male cables with BNC male connectors or interface between different equipment ports. The dual-female configuration acts as a high-quality coupler, allowing for versatile connectivity in laboratory testing, broadcast systems, and telecommunications. The precision-machined design ensures a constant 50 Ohm impedance and is optimized for signal integrity. Constructed with a heavy-duty nickel-plated brass body and PTFE (Teflon) insulation, it maintains low VSWR and exceptional durability up to 4 GHz.

Key Technical Advantages

• Standard Interface Integration: Enables seamless interoperability between professional N-Type infrastructure and widely available BNC-based test equipment.

• Dual-Socket Coupler: Serves as a reliable link for joining two different male cable standards in a single, compact unit.

• Superior RF Shielding: The solid brass construction and high-quality plating provide a continuous ground path, ensuring excellent protection against EMI and RFI interference.

• Rugged Mechanical Stability: The durable housing is designed to handle the mechanical stress associated with joining standard-sized coaxial cables.

• Maximum Conductivity: High-purity silver or gold plating on the internal center contact sockets ensures ultra-low contact resistance and superior protection against oxidation.

Key Features

• N Female to BNC Female Interface: Consists of an N-Type Jack (with socket and external threads) and a BNC Jack (with socket and bayonet studs).

• Nickel-Plated Brass Construction: Offers excellent electrical performance and superior corrosion resistance for both indoor and outdoor environments.

• Premium PTFE Dielectric: Offers high thermal stability and maintains consistent electrical performance across its frequency range.

• Industrial Durability: Rated for at least 500 mating cycles, ensuring long-term reliability in laboratory and field applications.

• Precision 50 Ohm Match: Specifically engineered to match standard communication and microwave test instrumentation.

🔹 Product Applications

• RF signal interface between N female and BNC female connectors
• Antenna and RF cable connections in telecom and communication systems
• RF test and measurement equipment setups
• Signal distribution in communication networks
• Broadcast and video transmission systems
• Laboratory and instrumentation RF connections
• RF coaxial cable assemblies and extensions
• Industrial RF and communication networks
• CCTV and surveillance system connectivity
• General RF connectivity in high-frequency applications
