N M CRIMP for LMR600 Cable

Description

The N-Type connector is the industry standard for high-performance microwave applications, prized for its exceptional power handling and low-attenuation characteristics. This male (plug) variant is specifically specialized for the 15.0mm (0.590″) cable class, optimized for high-performance LMR600. Because LMR600 is designed for ultra-low loss over long distances, this connector ensures that the transition from the large-diameter cable to the equipment port maintains maximum signal integrity and low VSWR.

This connector utilizes a professional crimp termination system designed for heavy-gauge conductors. The heavy-walled outer ferrule provides a high-strength 360-degree mechanical bond with the cable’s braid, while the oversized gold-plated center pin is typically soldered to the center conductor to ensure maximum signal stability and high-wattage power handling. Manufactured with a reinforced nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable operation up to 11 GHz. The threaded coupling provides superior mechanical stability and environmental sealing, making it ideal for outdoor cellular towers and military-grade communication arrays.

Key Technical Advantages

• LMR600 Precision Match: Specifically calibrated for the 0.590-inch OD cable family, ensuring maximum pull-off resistance and an optimized electrical transition for ultra-low-loss coaxial lines.

• High-Wattage Power Handling: Precision-engineered to support significantly higher power levels than smaller N-type variants, making it suitable for transmitters and main feeder jumpers.

• Vibration-Proof Threaded Interface: The 5/8-24 threaded mechanism provides a secure, locked connection that maintains electrical integrity in extreme outdoor and high-wind environments.

• Superior EMI/RFI Shielding: The solid metal construction and threaded design offer exceptional shielding, significantly reducing signal leakage and protecting high-bandwidth data transmission.

• Rugged Industrial Build: Features a nickel-plated brass body for maximum corrosion resistance and a gold-plated center contact for consistent signal clarity over the life of the installation.

Key Features

• Interface Type: N-Type Male (Plug) with standard 5/8-24 threaded coupling.

• Termination Method: Crimp (Outer Ferrule) / Solder (Center Pin).

• Cable Compatibility: Optimized for LMR600 and equivalent 0.590″ low-loss coaxial cables.

• Premium Construction: Features a nickel-plated brass body and high-performance PTFE dielectric.

• Common Application: Base station antennas, cellular infrastructure, long-haul RF links, and lightning protection systems.

Technical Summary
