SMB F RA CRIMP for BT3002 Cable

Description

The SMB Female Right-Angle (RA) Crimp Connector for BT3002 is a specialized RF interface designed to address the space constraints of modern telecommunications infrastructure. The 90-degree right-angle configuration allows for efficient cable routing in tight racks and chassis, enabling cables to run parallel to the equipment faceplate. This prevents excessive mechanical stress on the BT3002 cable’s minimum bend radius, which is critical for maintaining signal integrity in high-speed digital telephony and data transmission.

Precision-matched to a 75-Ohm impedance, this connector is tailored for the European telecommunications standard BT3002 (Type 2002) cable. It utilizes a professional-grade dual-crimp termination for both the center contact and the outer ferrule, ensuring an industrial-strength mechanical bond. The snap-on coupling mechanism provides a secure, tool-free connection that “clicks” into place, making it perfect for high-vibration environments and high-density patching. Manufactured with a gold-plated brass body and premium PTFE (Teflon) insulation, it delivers exceptional electrical stability and superior corrosion resistance for E1, E3, and DS3 applications.

Key Technical Advantages

• Low-Profile 90° Routing: Enables high-density port stacking and cleaner cable management by allowing the BT3002 cable to exit at a right angle, saving significant depth in equipment cabinets.

• BT3002-Specific Calibration: Precisely engineered to fit the 3.55mm outer diameter and electrical characteristics of BT3002 cable, ensuring a perfect 75-Ohm match and minimal return loss.

• Rapid Snap-On Efficiency: The spring-loaded mating mechanism facilitates immediate installation and maintenance in crowded digital distribution frames (DDF) without the need for threading tools.

• Superior Pull-Off Resistance: The dual-crimp design provides exceptional mechanical strength, protecting the sensitive signal path from accidental cable tension or displacement.

• Corrosion-Resistant Gold Plating: High-grade gold-over-nickel plating ensures a low-resistance electrical path and prevents oxidation in demanding telecommunications environments.

Key Features

• Interface Type: SMB Female (Jack) with 75-Ohm snap-on interface.

• Orientation: 90° Right Angle for space-saving cable management.

• Cable Compatibility: Optimized exclusively for BT3002 (Type 2002) 75-Ohm coaxial cable.

• Termination Style: Dual-crimp design (center pin and outer sleeve) for industrial-grade durability.

• Premium Construction: Built with a gold-plated brass body and a high-performance PTFE dielectric for thermal and electrical stability.
