TNC M RP CRIMP for LMR240 Cable

Description

The RP-TNC (Reverse Polarity TNC) series is a specialized RF interface widely used in wireless networking to comply with FCC and other regulatory standards for non-standard antenna connectors. In this Male (Plug) configuration, the connector maintains standard TNC male threads but utilizes a female center socket instead of a pin. This variant is specifically optimized for the 6.1mm (0.240″) low-loss cable class, providing a precision termination for LMR240 cables used in high-performance wireless links.

This connector utilizes a professional dual-crimp termination system. The outer ferrule creates a 360-degree mechanical bond with the cable’s braid and foil shielding, while the internal socket is precision-machined to ensure a secure electrical path when mating with RP-TNC female ports. Manufactured with a heavy-duty nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent electrical performance and stable impedance up to 6 GHz. The threaded interface provides superior mechanical stability and EMI shielding compared to bayonet-style connectors, making it ideal for high-vibration industrial and outdoor deployments.

Key Technical Advantages

• Reverse Polarity Compliance: Designed specifically for industrial Wi-Fi access points and routers that require RP-TNC interfaces for external antenna connections.

• LMR240 Precision Calibration: Specifically engineered to fit 0.240-inch OD cables, ensuring a seamless mechanical transition and high-strength pull-off resistance for low-loss cable runs.

• Vibration-Proof Threaded Coupling: The 7/16-28 threaded mechanism prevents signal intermittent issues and accidental disconnection, essential for mast-mounted and mobile wireless installations.

• Rugged 360° Crimp Termination: The heavy-walled ferrule provides a permanent, airtight grip on the cable jacket, protecting the internal dielectric from moisture ingress and environmental wear.

• Superior Environmental Durability: The nickel-plated brass construction and PTFE dielectric offer excellent resistance to thermal cycling and oxidation in demanding outdoor environments.

Key Features

• Interface Type: RP-TNC Male (Plug with Female Socket) with 7/16-28 threads.

• Termination Method: Crimp (Outer Ferrule) / Crimp or Solder (Center Socket).

• Cable Compatibility: Optimized for LMR240 and similar low-loss 50-Ohm coaxial cables.

• Premium Construction: Features a nickel-plated brass body and high-performance PTFE dielectric.

• Common Application: Wi-Fi antenna systems, industrial wireless bridges, WLAN routers, and cellular backhaul.

🔹 Applications:

• Reverse polarity RF connections
• Wireless communication systems
• Antenna connections
• Signal routing
• IoT devices
• Communication modules
