Description
The 7dBi High Gain 5G Whip Antenna is a state-of-the-art communication solution designed to deliver superior signal amplification and stability. With its expansive bandwidth covering 698MHz to 3800MHz, it is fully optimized for the global 5G spectrum, including the critical 3.5GHz mid-band, while maintaining seamless backward compatibility with all 4G LTE and 3G frequency bands. This makes it an indispensable component for high-speed 5G routers, industrial IoT gateways, and enterprise-grade cellular systems.
The antenna features a high-efficiency whip radiator designed for maximum reach in signal-congested or fringe areas. It is encased in a ruggedized, UV-stabilized ABS radome that provides excellent protection against environmental factors. Its omni-directional radiation pattern ensures consistent 360-degree coverage, capturing signals effectively from multiple cell towers simultaneously. This eliminates the need for manual alignment and provides a robust, reliable link for stationary, mobile, or remote deployments.
Key Technical Advantages
-
Future-Proof 5G Coverage: Supports the full Sub-6GHz 5G NR spectrum (up to 3.8GHz), ensuring high-speed data performance for modern and upcoming network deployments.
-
Superior 7dBi High Gain: Provides enhanced signal sensitivity and increased range compared to standard antennas, significantly improving upload/download speeds in weak signal zones.
-
360° Omni-Directional Pattern: Delivers a complete horizontal beamwidth for effortless signal acquisition, making it ideal for environments where the tower location is unknown or may change.
-
Ultra-Wideband Versatility: A single-antenna solution that replaces the need for multiple bands, covering everything from low-band 700MHz to high-band 3.8GHz.
-
Low VSWR Performance: Precision-matched internal circuitry ensures minimal signal reflection and maximum power transfer, protecting the longevity of connected radio equipment.
Key Features
-
Frequency Range: 698 – 3800 MHz (Ultra-Wideband).
-
Gain: 7 dBi.
-
Radiation Pattern: Omni-Directional.
-
Polarization: Vertical.
-
Impedance: 50 Ohm (Standard).
-
Connector Type: SMA Male (Standard) / N-Type (Optional).
-
Common Application: 5G/4G Routers, CPE devices, Industrial IoT, M2M gateways, and cellular signal enhancement systems.
Technical Summary
| Parameter | Specification |
| Impedance | 50 Ohm |
| Frequency Range | 698 – 3800 MHz |
| VSWR | ≤ 2.5:1 |
| Gain | 7 dBi |
| Polarization | Vertical |
| Horizontal Beamwidth | 360° |
| Operating Temp | -40°C ~ +85°C |
