High Gain 12dBi LPDA Antenna 698-2700MHz

Description

The 12dBi LPDA Antenna is a high-performance directional wideband antenna designed to provide a stable, high-gain connection across all major cellular frequencies. Unlike standard yagi antennas that operate on narrow bands, the Log-Periodic design allows for consistent performance across the entire 698-2700MHz range. This makes it compatible with all global cellular carriers, covering essential bands such as 700MHz (B12/B13/B17/B28), 850MHz (B5), 1800MHz (B3), 2100MHz (B1), and 2600MHz (B7).

Constructed with a weatherproof ABS radome and high-grade aluminum internal elements, this antenna is built to withstand extreme outdoor conditions, including high winds, heavy rain, and UV exposure. The directional nature of the LPDA focus energy in a specific direction, significantly reducing interference and providing a massive 12dBi gain boost. This is particularly effective for remote locations where the nearest cell tower is miles away or for urban environments where building penetration is a challenge. It typically features an integrated N-Female connector for low-loss cable attachment.

Key Technical Advantages

• Ultra-Wideband Coverage: Consolidates multiple antennas into one, supporting everything from low-frequency 700MHz coverage to high-frequency 2700MHz data bands.

• Superior 12dBi Directional Gain: Provides highly focused signal power, capable of reaching distant towers that omni-directional antennas cannot detect.

• Low VSWR Performance: Precision-engineered to maintain a Voltage Standing Wave Ratio (VSWR) of less than 1.5, ensuring maximum power transfer and protecting your cellular booster or modem.

• Ruggedized Outdoor Construction: The UV-stabilized ABS housing and heavy-duty mounting hardware ensure long-term reliability in harsh climates.

• Multi-Carrier Compatibility: Works seamlessly with all cellular service providers and is ideal for use with signal boosters, 4G/5G routers, and industrial IoT gateways.

Key Features

• Antenna Type: Log-Periodic Dipole Array (LPDA).

• Frequency Range: 698-960 / 1710-2700 MHz.

• Gain: 12 dBi.

• Polarization: Vertical or Horizontal.

• Connector Type: N-Female (Standard).

• Housing Material: Weatherproof ABS Radome.

• Common Applications: Rural 4G/LTE signal enhancement, remote site monitoring (IoT), cellular signal booster outdoor donor antenna, and fringe-area broadband.

🔹 Applications:

• Multi-band telecom signal reception (2G/3G/4G/LTE)
• Outdoor base station and repeater systems
• DAS and IBS installations
• Long-range RF communication
• Rural and remote network coverage
• Wireless broadband systems
