N F BH CLAMP for LMR100/RG174/RG316 Cable

Description

The N-Type female bulkhead connector is a fundamental component for secure chassis interfacing, valued for its mechanical stability and superior grounding. This variant features a Bulkhead (BH) mounting design, including a mounting nut and washer, which allows for a high-integrity, fixed connection through enclosure walls. It is specialized for the 2.5mm to 3mm cable class, specifically optimized for high-performance LMR100 and high-temperature RG316.

Unlike crimp-style connectors that require specialized tooling, this variant utilizes a mechanical clamp termination system. This design employs an internal compression sleeve to secure the cable braid, providing a high-strength, reusable connection that can be assembled on-site with standard wrenches. As a female interface (jack), it provides a rugged external threaded mating point, allowing for a seamless transition from internal micro-coaxial jumpers to external antenna systems. Manufactured with a durable nickel-plated brass body and premium PTFE (Teflon) insulation, it ensures consistent 50-Ohm performance and reliable operation up to 6 GHz.

Key Technical Advantages

• Field-Installable Design: The clamp-style assembly allows for high-integrity terminations without the need for specialized crimping tools, ideal for on-site repairs and custom installations.

• Secure Bulkhead Mounting: The threaded body and hex-nut design provide a robust, non-rotating mounting solution through panels, ensuring a stable ground connection to the chassis.

• Thin-Gauge Cable Match: Specifically calibrated for the 0.100″ to 0.110″ OD cable family, ensuring maximum pull-off resistance and an optimized electrical transition for thin coaxial lines.

• Vibration-Proof Threaded Interface: The 5/8-24 threaded outer shell ensures a secure, locked mating with male connectors, resisting loosening in high-vibration or mobile environments.

• High-Grade Materials: Features a nickel-plated brass body and a gold-plated center contact for maximum corrosion resistance and consistent signal clarity over the life of the product.

Key Features

• Interface Type: N-Type Female (Jack) with standard 5/8-24 threaded outer shell.

• Mounting Type: Bulkhead (Through-Panel Mount) with Nut and Washer.

• Termination Method: Clamp (Outer Braid) / Solder (Center Pin).

• Cable Compatibility: Optimized for LMR100, RG174, RG188, RG316, and equivalent 50-Ohm thin coaxial cables.

• Premium Construction: Features a nickel-plated brass body and high-performance PTFE dielectric.

• Common Application: RF equipment enclosures, cellular IoT modules, internal cabinet routing, and laboratory test fixtures.
