The N-Type connector is the premier choice for infrastructure-grade RF applications, valued for its mechanical robustness and superior power handling. This Right Angle (RA) variant is specialized for the 10.3mm (0.405″) cable class, specifically optimized for high-performance LMR400 and high-temperature RG393. The 90-degree elbow configuration is essential for tight-access cabinets and bulkhead interfaces, allowing for streamlined cable routing without compromising the cable’s minimum bend radius, which ensures optimal signal throughput and prevents internal dielectric damage.
This connector utilizes a standard hex-crimp termination system for the outer conductor. This provides a high-strength, 360-degree mechanical bond that is highly resistant to pull-off and vibration, making it ideal for mobile and fixed outdoor environments. Manufactured with a heavy-duty nickel-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and low VSWR up to 11 GHz. The center contact is designed for soldering to ensure a permanent, high-integrity electrical connection with the cable’s center conductor.
Key Technical Advantages
-
Compact 90° Routing: The right-angle design significantly reduces the depth required for connections, making it perfect for small enclosures, cabinet interiors, and high-density interface panels.
-
Large-Gauge Cable Match: Specifically calibrated for the 0.405-inch OD cable family, ensuring a seamless mechanical fit and an optimized electrical transition for thick, low-loss coaxial lines.
-
Secure Crimp Termination: The hex-crimp sleeve provides a robust mechanical grip on the cable braid, offering excellent strain relief and maximum EMI/RFI shielding.
-
Vibration-Proof Threaded Interface: The 5/8-24 threaded coupling ensures a secure, locked connection that maintains signal continuity in high-wind or high-vibration outdoor environments.
-
High-Grade Materials: Features a nickel-plated brass body and a gold-plated center contact for maximum corrosion resistance and stable signal clarity over the life of the installation.
Key Features
-
Interface Type: N-Type Male (Plug) Right Angle (90°) with standard 5/8-24 threaded coupling.
-
Termination Method: Crimp (Outer Braid) / Solder (Center Pin).
-
Cable Compatibility: Optimized for LMR400, RG8, RG213, RG393, and equivalent 0.405″ 50-Ohm coaxial cables.
-
Premium Construction: Features a nickel-plated brass body and high-performance PTFE dielectric.
-
Common Application: Cellular base stations, high-power antenna feeders, maritime communication, and industrial RF arrays.
🔹 Applications:
- High-power RF systems
- Telecom base stations
- Antenna feeder lines
- Broadcast systems
- Outdoor RF installations
- RF infrastructure
