SAA or 1.0/2.3 M THREADED CRIMP TYPE for BT3002 Cable

Description

The SAA series, or 1.0/2.3 connector, is a subminiature RF interface optimized for the high-density requirements of modern digital telephony. This male (plug) variant features a threaded coupling mechanism, distinguishing it from the standard push-pull versions. The threaded design provides a superior mechanical lock, making it the ideal choice for environments subject to high vibration or where a permanent, fixed connection is required to ensure 100% network uptime.

Specifically calibrated for BT3002 (Type 2002) cable—the industry standard for E1, E3, and DS3 digital signal transmission—this connector maintains a strict 75-Ohm impedance. It utilizes a professional dual-crimp termination for both the center pin and the outer ferrule, ensuring a gas-tight mechanical bond and excellent pull-off resistance. Manufactured with a gold-plated brass body and premium PTFE (Teflon) insulation, it delivers exceptional signal integrity and low return loss up to 3 GHz, protecting sensitive digital data streams from interference and reflection.

Key Technical Advantages

• Secure Threaded Coupling: The screw-on interface provides maximum retention force, preventing signal interruptions caused by accidental cable pulls or vibration.

• BT3002 Precision Matching: Engineered specifically for the 0.31mm center conductor and 3.55mm OD of Type 2002 cable, ensuring an optimized electrical transition.

• 75-Ohm System Integrity: Strict impedance control prevents bit errors and signal jitter in high-capacity digital telephony and broadcast circuits.

• Industrial Dual-Crimp Design: Provides a high-strength, repeatable termination that is faster and more consistent than soldering for large-scale infrastructure projects.

• Superior Corrosion Resistance: Premium gold-over-nickel plating on all critical surfaces ensures low contact resistance and long-term durability in professional exchange environments.

Key Features

• Interface Type: SAA / 1.0/2.3 Male (Plug) with 75-Ohm threaded coupling.

• Termination Method: Dual-crimp (center pin and outer ferrule) for high-reliability mechanical bonding.

• Cable Compatibility: Optimized exclusively for BT3002 (Type 2002) 75-Ohm coaxial cable.

• Premium Construction: Features a gold-plated brass body and a high-performance PTFE dielectric for electrical stability.

• Application: Ideal for critical Digital Distribution Frame (DDF) links and high-reliability telecommunications exchange hardware.
