Description
The SMA Female SMT (Surface Mount Technology) PCB Connector is a high-performance RF interface engineered for modern, high-density electronic assemblies. Designed to be soldered directly onto the top conductive layer of a printed circuit board, this connector eliminates the need for through-holes, preserving the integrity of internal PCB ground planes and making it ideal for multi-layer board designs.
Optimized for Automated Manufacturing
This connector features a flat base and specialized lead geometry compatible with standard pick-and-place machines and reflow soldering processes. The compact footprint and straight vertical orientation allow for high-density port arrays in networking equipment, small cells, and embedded wireless systems.
Key Technical Advantages:
-
Surface Mount Design: Facilitates faster production cycles and reduces assembly costs by supporting fully automated SMT lines.
-
Superior Signal Integrity: Optimized for a stable 50 Ohm impedance from DC to 6 GHz (and up to 12.4 GHz depending on board layout), ensuring minimal return loss for high-speed data.
-
Compact Vertical Profile: Ideal for top-entry antenna connections in compact enclosures where side-space is limited.
-
Premium Gold Plating: The high-purity gold finish on the brass body and center contact ensures excellent solderability and long-term protection against environmental oxidation.
-
High-Temperature Tolerance: Constructed with top-grade PTFE (Teflon) insulation to withstand the thermal stresses of infrared reflow and convection soldering.
Key Features
-
Connector Type: SMA Female (Jack) with internal threads.
-
Orientation: Straight (Vertical).
-
Mounting Type: SMT / SMD (Surface Mount Device).
-
Impedance: 50 Ohm (Standard for professional RF).
-
Durability: Rated for 500+ mating cycles.
-
Construction: Gold-plated brass for maximum conductivity.
Applications:
• SMT PCB RF Circuits
• High Frequency Signal Transmission
• Wireless Communication Devices
• WiFi & Bluetooth Modules
• IoT Devices
• RF Test & Measurement Equipment
• GPS Modules
• Antenna PCB Applications
