Description
The SMA Male Solder Connector for RG.086 is a professional-grade RF component optimized for high-performance signal transmission. Because RG.086 (also known as RG405) features a solid or braided silver-plated copper outer conductor, this connector utilizes a direct-solder body attachment.
The cable’s outer conductor is soldered 360 degrees directly to the connector body, creating a seamless, gas-tight mechanical and electrical bond. This method eliminates the signal leakage and passive intermodulation (PIM) often found in crimp-style connectors. It is the preferred choice for RF power amplifiers, internal chassis wiring, and laboratory test fixtures operating in the DC to 18 GHz range, where maintaining an ultra-low VSWR is critical.
Key Technical Advantages
-
Superior RF Shielding: The direct-solder transition between the cable shield and connector body provides nearly 100% EMI/RFI protection.
-
Ultra-Low VSWR: Precision-machined to maintain a strict 50 Ohm impedance path, minimizing signal reflection even at microwave frequencies.
-
Maximum Mechanical Bond: The soldered joint ensures the connector remains stable under extreme thermal expansion and high-vibration conditions.
-
High Power Handling: The solid metal-to-metal contact allows for better heat dissipation and higher power throughput compared to crimp alternatives.
Key Features
-
Direct-Solder Termination: Optimized specifically for the .086″ diameter of semi-rigid and hand-formable cables.
-
Teflon (PTFE) Insulator: Features a premium dielectric for superior electrical performance and heat resistance during the soldering process.
-
Standard 1/4-36 Threaded Nut: Ensures a secure, high-torque connection with any standard SMA female (jack) interface.
-
Gold-Plated Center Pin: Provides a low-resistance contact point for precise high-speed signal transmission.
-
Broad Frequency Support: Reliably handles signals from DC up to 18 GHz.
Applications:
• RG .86 Cable Termination
• Compact RF Cable Assemblies
• Microwave Communication Systems
• Antenna Cable Connections
• RF Test & Measurement Equipment
• Aerospace & Defense Applications
• Wireless Communication Systems
• RF Signal Transmission
