Description
The SMC Female (Jack) Solder Type Connector for .141/RG402 is an ultra-stable RF interface engineered for applications where signal leakage and phase stability are paramount. Semi-rigid cables like .141 (RG402) are the gold standard for high-frequency microwave systems due to their solid copper outer jacket, which offers 100% shielding effectiveness. This SMC connector is precision-machined to allow the cable’s outer conductor to be soldered directly to the connector body, creating a continuous, fused electrical path that eliminates the variables associated with mechanical crimping.
Operating from DC up to 10 GHz, the SMC interface utilizes a threaded #10-32 coupling mechanism. This provides a secure, vibration-resistant connection that is significantly more stable than snap-on alternatives, making it ideal for military avionics and high-performance wireless infrastructure. The connector is manufactured with a gold-plated brass body and premium PTFE (Teflon) insulation to ensure low VSWR (Voltage Standing Wave Ratio) and exceptional thermal stability during the soldering process and throughout its operational life.
Key Technical Advantages
-
Seamless Solder Termination: The direct-solder design for the outer jacket and center conductor ensures maximum shielding effectiveness and the lowest possible return loss at microwave frequencies.
-
RG402 / .141 Precision Fit: Specifically calibrated to the dimensions of 0.141-inch semi-rigid and conformable cables, ensuring perfect mechanical alignment and 50-Ohm impedance matching.
-
Threaded Mechanical Stability: The #10-32 threaded interface ensures constant contact pressure and prevents accidental decoupling in high-vibration aerospace and laboratory environments.
-
Microwave Frequency Range: Optimized to support stable signal transmission up to 10 GHz, suitable for X-band radar, satellite communications, and precision RF instrumentation.
-
Superior Corrosion Protection: High-grade gold-over-nickel plating on the body and contact surfaces ensures low contact resistance and prevents oxidation in demanding environments.
Key Features
-
Interface Type: SMC Female (Jack) with 50-Ohm threaded interface.
-
Cable Compatibility: Optimized for .141″ Semi-Rigid, RG402, and .141-inch Conformable/Hand-Formable cables.
-
Termination Method: Solder-solder (Direct solder for both center conductor and outer jacket).
-
Industrial Construction: Features a gold-plated brass body and a high-performance PTFE dielectric to withstand soldering heat.
-
Low Signal Leakage: The fused solder connection provides superior EMI/RFI shielding compared to standard crimp connectors.
Technical Summary
| Parameter | Specification |
| Impedance | 50 Ohm |
| Frequency Range | DC – 10 GHz |
| Body Material | Brass (Gold Plated) |
| Contact Material | Beryllium Copper (Gold Plated) |
| Insulator | PTFE (Teflon) |
| Coupling Mechanism | #10-32 Threaded |
| Operating Temp | -65°C ~ +165°C |
