Description
The N-Type connector is a staple in high-frequency engineering, valued for its durability and excellent microwave performance. This male (plug) variant is specialized for the 2.18mm (0.086″) semi-rigid cable class, including RG405. Because semi-rigid cables utilize a solid copper outer conductor, this connector employs a direct-solder termination method. This creates a permanent, airtight mechanical and electrical bond that provides superior performance compared to mechanical crimping for small-diameter microwave lines.
By eliminating the crimp ferrule and soldering the cable’s outer jacket directly to the connector body, this plug ensures maximum EMI shielding and minimizes signal leakage. The design provides a phase-stable connection, which is critical for precision instrumentation, satellite communication systems, and cellular infrastructure where low VSWR and signal purity are required. Manufactured with a heavy-duty nickel or silver-plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and reliable operation up to 18 GHz.
Key Technical Advantages
-
Optimized for RG405/0.086″: Precision-machined internal bore designed specifically for the dimensions of .086″ semi-rigid cables, ensuring a perfect fit and a clean solder flow.
-
Direct-Solder Integrity: The solder-on body design creates a seamless 360-degree electrical path, significantly reducing insertion loss and VSWR at microwave frequencies.
-
Rugged Threaded Coupling: The 5/8-24 threaded interface provides a secure, vibration-proof connection, maintaining stability in aerospace, military, and industrial environments.
-
Maximum EMI/RFI Shielding: The solid-to-solid solder connection provides an exceptionally shielded transition, protecting sensitive signals from external interference.
-
Microwave Frequency Support: Engineered to maintain high-grade performance up to 18 GHz, making it suitable for modern high-bandwidth wireless and radar systems.
Key Features
-
Interface Type: N-Type Male (Plug) with standard 5/8-24 threaded coupling.
-
Termination Method: Solder (Outer Body) / Solder (Center Pin).
-
Cable Compatibility: Optimized for RG405 and .086″ Semi-Rigid or Conformable coaxial cables.
-
Premium Construction: Features a high-grade plated brass body and performance PTFE dielectric.
-
Common Application: RF microwave modules, phase-matched jumpers, laboratory test equipment, and satellite links.
🔹 Applications:
- Microwave RF cable assemblies
- High-frequency communication systems
- RF test setups
- Precision signal transmission
- Lab and research applications
- Aerospace RF systems
