Mini DIN Male to N Female RA Adapter

Description

The Mini DIN (4.3-10) Male to N Female Right Angle Adapter is a specialized between-series RF component designed to provide a high-reliability transition while solving cable routing challenges. It features a 4.3-10 Plug (Male) on one side and an N-Type Jack (Female) on the other, integrated into a precision-machined 90-degree housing. This “Right Angle” geometry allows for clean cable management, preventing excessive stress and bending of coaxial cables in high-density small cell and DAS deployments.

This adapter is essential for engineers who need to connect N-Type male cable assemblies to 4.3-10 equipment ports located in cramped quarters. The precision-machined design ensures a constant 50 Ohm impedance and is specifically optimized to maintain low Passive Intermodulation (PIM) levels, ensuring signal purity in multi-carrier 4G and 5G networks. Constructed with a heavy-duty tri-metal (white bronze) plated brass body and PTFE (Teflon) insulation, it maintains exceptional signal integrity and low VSWR up to 6 GHz.

Key Technical Advantages

• Space-Saving 90-Degree Profile: Allows for efficient cable routing in tight spaces, reducing the physical footprint and preventing mechanical strain on equipment ports.

• Low-PIM Optimization: Engineered to minimize passive intermodulation, which is critical for maintaining maximum data throughput in modern cellular environments.

• Vibration-Proof Threaded Mating: Both the Mini DIN and N-Type interfaces utilize secure threaded coupling, ensuring a stable connection that resists loosening in outdoor tower environments.

• Superior RF Shielding: The solid brass right-angle housing provides an exceptional ground path, protecting against EMI and RFI interference.

• Maximum Conductivity: High-purity silver plating on the internal center contact pin and socket ensures ultra-low contact resistance and superior protection against oxidation.

Key Features

• 4.3-10 Male to N Female RA Interface: Consists of a 4.3-10 Plug (with pin and hex nut) and an N-Type Jack (with socket and external threads) in a right-angle configuration.

• Tri-Metal / White Bronze Plating: Offers superior electrical conductivity and a non-magnetic finish that significantly reduces PIM compared to standard nickel plating.

• Premium PTFE Dielectric: Offers high thermal stability and maintains consistent electrical performance across its frequency range.

• Industrial Durability: Rated for at least 500 mating cycles, ensuring long-term reliability in professional cellular and broadcast environments.

• Rugged Mechanical Design: Built to withstand high-torque installations and extreme environmental conditions in outdoor base station applications.

🔹 Applications

• RF signal interface between Mini DIN male and N female right-angle connectors
• Antenna and RF cable connections in telecom systems
• Telecom base stations and wireless communication infrastructure
• High-frequency RF transmission systems
• RF coaxial cable assemblies and extensions
• Space-constrained installations using right-angle RF connectors
• Outdoor antenna installations and industrial RF networks
• RF test and measurement equipment
• Signal distribution systems for mobile networks
• Wireless communication and networking systems
