N F CLAMP for 7/8″ Feeder Cable

Description

The N-Type female connector is a critical component for large-scale RF infrastructure, valued for its mechanical durability and superior power handling. This variant is specialized for the 7/8″ corrugated cable class. At this diameter, cables utilize a thick, annularly corrugated copper outer conductor to provide exceptionally low attenuation and 100% shielding effectiveness. This connector is specifically engineered with a high-compression mechanical clamp that interlocks with these large corrugations, ensuring a high-strength, 360-degree electrical bond that maintains the cable’s superior signal integrity.

As a female interface (jack), it is frequently used to provide a rugged threaded mounting point for primary feeder lines entering equipment shelters or as the main receptacle for high-power distribution arrays. The mechanical compression clamp termination provides an airtight, low-resistance connection optimized for Passive Intermodulation (PIM) stability. This design allows for precision, high-strength terminations on-site using standard wrenches, facilitating efficient installation and system maintenance in demanding tower-top or base station environments. Manufactured with a heavy-duty tri-metal plated brass body and premium PTFE (Teflon) insulation, it delivers consistent 50-Ohm performance and low VSWR across wide frequency bands.

Key Technical Advantages

• 7/8″ Corrugated Cable Match: Specifically engineered for the annular corrugation profile of 7/8″ feeder cables, ensuring maximum surface contact and extreme pull-off resistance.

• Low-PIM Performance: The precision-machined clamp interface minimizes non-linearities, a critical requirement for modern multi-carrier LTE and 5G networks to prevent signal degradation and interference.

• Field-Installable Design: The mechanical compression system allows for high-integrity assembly on-site without specialized crimping tools, ideal for rapid infrastructure deployment and maintenance.

• Vibration-Proof Threaded Interface: The 5/8-24 threaded outer shell ensures a secure, locked mating with male connectors that resists loosening in high-wind or high-vibration environments.

• IP68 Environmental Sealing: Features multiple integrated O-ring gaskets to provide a moisture-proof barrier, protecting the cable interface from oxidation and harsh weather conditions.

Key Features

• Interface Type: N-Type Female (Jack) with standard 5/8-24 threaded outer shell.

• Termination Method: Compression Clamp (Outer Conductor) / Solder or Captive (Center Pin).

• Cable Compatibility: Optimized for 7/8″ Annular Corrugated Feeder Cables (LDF5-50A, AVA5-50, etc.).

• Premium Construction: Features a tri-metal plated brass body and high-performance PTFE dielectric.

• Common Application: Primary antenna feeders, cellular base station interfaces, tower-top enclosures, and high-power RF distribution.

🔹 Applications:

• High-power RF feeder systems
• Telecom base stations
• Antenna installations
• Outdoor RF networks
• Signal transmission
• Broadcast systems
