6 WAY FEEDER CLAMP FOR LMR400 CABLE

Description

The 6-Way Feeder Clamp for LMR-400 is an ultra-high-density mounting solution designed to maximize space efficiency in complex wireless deployments. It is specifically sized to accommodate the outer diameter of LMR-400 series cables (approx. 10.29mm). The assembly utilizes independent UV-resistant polypropylene (PP) saddles arranged in a multi-run configuration within a heavy-duty SUS304 stainless steel C-bracket, allowing six separate cables to be secured in a single, organized mechanical interface.

This clamp is indispensable for large-scale MIMO antenna arrays, high-capacity small cells, and centralized signal distribution hubs where massive cable counts must follow a single path. By providing a secure, vibration-resistant attachment point for six cables, it prevents signal degradation caused by cable-on-cable friction and ensures a clean, professional installation. The high-quality stainless steel components guarantee a rust-free lifespan in even the most corrosive coastal environments, while the high-density design drastically reduces the mounting footprint required on tower members.

Key Technical Advantages

• Ultra-High-Density Efficiency: Secures six LMR-400 cables within a single mounting point, offering the highest possible cable-to-space ratio on crowded tower members.

• LMR-400 Precision Fit: The plastic saddles are calibrated to provide a firm, non-slip grip on the cable jacket without over-compressing the dielectric, preserving critical signal integrity.

• Superior Corrosion Resistance: All metallic components, including the reinforced C-bracket and threaded rod, are manufactured from SUS304 stainless steel for maximum longevity in outdoor settings.

• UV and Weather Stability: The plastic hanger inserts are formulated with industrial-grade UV stabilizers to maintain structural flexibility and prevent embrittlement under prolonged solar exposure.

• Streamlined Cable Management: Drastically reduces clutter and simplifies inspection by organizing six independent signal paths into a single, robust mechanical assembly.

Key Features

• 6-Way Configuration: Specifically designed to secure six independent cables per clamp assembly.

• LMR-400 Compatibility: Optimized for all LMR-400 series cables, including Ultraflex, Plenum, and 400-series equivalents (e.g., RG-8, CNT-400).

• Reinforced C-Bracket: A heavy-duty stainless steel frame designed to maintain constant tension and withstand extreme wind loading across all six cable positions.

• Complete Hardware Set: Includes six UV-resistant saddles, a stainless steel bracket, a threaded rod, flat washers, spring washers, and hex nuts.

• Modular Infrastructure Ready: Designed for immediate attachment to standard angle adapters, round members, or tower ladder rungs.

Technical Summary
